Comco-Cotton hard fabric

Comco EPP Produkte - Baumwollhartgewebe

Thermoset laminate made of cotton fabric sheets as a carrier material and phenol/formaldehyde resin as a binder. This high-quality material is suitable for a wide range of applications in mechanical engineering due to its good mechanical properties, such as high wear resistance, noise and vibration damping.

Standard colour: brown

Material properties:

  1. continuous operating temperature at 120 °C
  2. very good mechanical workability
  3. suitable for applications in oil and air with normal ambient humidity

Application examples:

  • sealing rings
  • insulating rails

Sheets: Sizes: 2800 x 1220 mm and 2150 x 1220 mm standard (tol. +/-).
Other formats also available.

Thicknesses: 0,2-150 mm

Round tubes and rods: Available in various dimensions.

Download the thermoset finished parts catalogue (DE)
Comco-Cotton hard fabric – variants
  • Sheets
  • Round Tubes
  • Round Rods

Comco-PF CC 201 / HGW 2082
Good electrical properties for applications as a construction element in the low-voltage range.

Comco-PF CC 202 / HGW 2082.5
Good dielectric properties with low moisture absorption.

Comco-PF CC 203 / HGW 2083
The ultra-fine fabric processed here makes this material suitable for precise construction elements and applications with high mechanical requirements.

Comco-PF CC 204 / HGW 2083.5
The ultra-fine fabric processed here makes this material suitable for precise construction elements and applications with high mechanical and electrical requirements.

Comco-MF CC 201 / HGW 2282.5
Good electrical properties for applications in the low-voltage range, increased tracking resistance and additionally a flammability class V0 according to UL94.

PF CC 21 / HGW 2086
Coiled round tubes with very good mechanical and electrical properties for applications as construction elements in the low-voltage range.

Comco-PF CC 22 / HGW 2085
Coiled round tubes with normal mechanical and good electrical properties for applications as construction elements in the low-voltage range.

Comco-PF CP 41 / HP 2068
Pressed round rods for applications as construction elements with good mechanical and electrical properties.
